Prana Air

Pro

Ambiente
Monitor de Qualidade do Ar

Dispositivo mais avançado para profissionais e pesquisadores que buscam dados mais precisos sobre a qualidade do ar.

Solicitar Orçamento

prana air ambient pro air quality monitor

Ambient Monitor Variants

Os dispositivos de monitoramento da qualidade do ar ambiente da Prana Air são onde sua pesquisa termina.

Ambient PM

It is the basic ambient monitor that measures AQI, PM2.5, PM10, temperature, and humidity providing a comprehensive overview of the air quality around you.

Features

  • low cost icon

    Low-cost real-time air quality monitoring

  • compact device

    Compact and lightweight design

  • weatherproof icon

    Fully Waterproof Housing

  • portable icon

    Portable and easy to carry anywhere

  • AQI
  • PM1
  • PM2.5
  • PM10
  • Temp.
  • Humid.
Prana Air ambient pm monitor with weather station

Ambient PM & Weather Station

A comprehensive solution for air quality monitoring, providing accurate measurements of PM2.5, PM10, temperature, and humidity

Ambient PM Monitor With Weather Station

Prana Air Ambient PM Basic Monitor is a comprehensive solution for measuring air quality. It accurately measures PM2.5, PM10, temperature, and humidity, providing you with valuable insights into the air you breathe. With an optional weather station, you can also gain data on wind speed, wind direction, rainfall, and barometric pressure. The compact and portable design of the Prana Air Ambient PM Basic Monitor makes it easy to use anywhere. The clear and easy-to-read screen displays real-time data, and built-in data logging allows you to track trends over time. Cloud connectivity provides remote access to data, so you can stay informed about air quality even when you're not on site.

prana air ambient air quality monitor for constructions site

Ambient PM With Weather Station

prana air ambient air quality monitor at house

Ambient Lite

It is a mid-range model that is ideal for small businesses and community organizations. It measures PM2.5, PM10, CO2, SO2, NO2, O3, temperature, humidity.

Features

  • low cost icon

    Low-cost real-time air quality monitoring

  • cloud storage

    Cloud storage & web-dashbard & apps

  • weatherproof icon

    Fully Waterproof Housing

  • multiple sensors

    Multiple sensors available

  • AQI
  • PM1
  • PM2.5
  • PM10
  • CO
  • CO2
  • SO2
  • NO
  • NO2
  • O3
  • TVOC
  • H2S

  • Temp.
  • Humid.

Ambient Lite Air Quality Monitor

Prana Air Ambient Lite Monitor is a versatile and affordable solution for measuring air quality. In addition to the parameters measured by the Ambient PM Monitor, the Ambient Lite Monitor also measures SO2, NO2, O3, CO, CO2, NO, H2S, TVOC, etc. This makes it an ideal choice for users who want a more comprehensive understanding of air quality. It is also equipped with a built-in air quality index (AQI) calculator. The AQI is a standardized measure of air quality that is used by government agencies and environmental organizations around the world. The AQI provides a quick and easy way to understand the overall air quality in a particular location.

ambient lite moitor for street pollution monitoring

Ambient Pro

It is the most advanced monitor in Prana Air's Ambient family. It measures all of the same pollutants as the Ambient Lite monitor, plus temperature and humidity.

Features

  • low cost icon

    Low-cost air quality monitors

  • online data access

    Data on website, mobile & table apps, TV

  • weatherproof icon

    Fully Waterproof Housing

  • multiple sensors icon

    Multiple air sensors (PM & Gases)

  • AQI
  • PM1
  • PM2.5
  • PM10
  • CO
  • CO2
  • SO2
  • NO
  • NO2
  • O3
  • CH4
  • TVOC
  • H2S

  • Temp.
  • Humid.
  • Noise
  • Wind Direction
  • Wind Speed
  • Rainfall
  • LUX
  • UV Index
prana air ambient pro monitor variants

Ambient Pro Monitor

It is the most advanced ambient air quality monitor of Prana Air that comes with inbuilt weather station.

Ambient Pro Inbuilt Weather Station

The primary aspect for determining environmental stability is the Continuous Ambient Air Quality Monitoring System (CAAQMS). There are many factors that control the quality of air and many sources contributing to it such as natural, industrial and anthropogenic. Meteorological factors also alter and impact air quality. Outdoor air pollution does not just jeopardize the living. It is also detrimental to the ecology and the atmospheric chemistry of the earth. Chronic Obstructive Pulmonary Disease (COPD) and asthma are examples of bad air quality for human health.

prana air ambient pro air quality monitor in used

Por que os monitores de ar ambiente da Prana Air?

  • Real-time air quality monitoring

    Monitoramento da qualidade do ar em tempo real

  • Low-cost monitors & sensors

    Qualidade do ar de baixo custo
    monitores/sensores

  • accurate sensors

    Altamente preciso
    e confiável
    sensores

  • cloud data access

    Acessibilidade de dados
    no site, celular e celular Aplicativos de TV

  • modes of data connectivity

    Multiple modes of connectivity

  • low cost maintenance

    Baixo custo
    manutenção
    despesa

Aplicações do Monitor de Qualidade do Ar Ambiente

Protecting public health and improving the environment in a variety of industries

Prana Air construction site air quality monitor

Os canteiros de obras são uma importante fonte de poeira e outros poluentes. A Prana Air pode ajudar os locais de construção a monitorar os níveis de qualidade do ar e a tomar medidas para reduzir as emissões.

Local de construção

Prana Air parking lot air quality monitor

Os estacionamentos são uma importante fonte de emissões veiculares. Nossa solução pode ajudar os operadores de estacionamentos a monitorar seus níveis de qualidade do ar e a tomar medidas para reduzir as emissões.

Parking Lots

Prana Air smart city air quality monitor

Os projetos de cidades inteligentes estão incorporando cada vez mais o monitoramento da qualidade do ar em seus projetos. A solução de qualidade do ar ambiente da Prana Air pode ajudar projetos de cidades inteligentes a monitorar seus níveis de qualidade do ar.

Projeto Cidade Inteligente

Prana Air real estates air quality monitor

Os novos empreendimentos imobiliários estão frequentemente localizados em áreas com má qualidade do ar. A solução da Prana Air pode ajudar incorporadores imobiliários a identificar áreas com boa qualidade do ar.

Real Estates

Prana Air RMC air quality monitor

As usinas de concreto pronto são uma importante fonte de poluição do ar, emitindo partículas, poeira e outros poluentes. Nossa solução pode ajudar as fábricas da RMC a monitorar seus níveis de qualidade do ar.

RMC Plant

prana air airport air quality monitor

Os aeroportos são outra importante fonte de poluição do ar, emitindo poluentes de aeronaves, veículos e outras fontes. A solução de qualidade do ar ambiente da Prana Air pode ajudar os aeroportos a monitorar seus níveis de qualidade do ar.

Airports

Parts & Labels

ambient-pm-monitor-pranaair

  • wifi switch

    Interruptor Wi-Fi

  • sim slot

    Slot SIM

  • power supply

    Poder

  • pm inlet

    Entrada PM

ambient-lite-monitor-pranaair

  • Fan

    Fan

  • micro sd card

    Slot para cartão Micro SD

  • rs-485

    Slot RS-485

  • sim slot

    SIM Slot

  • usb power supply

    Fonte de alimentação USB


  • Slot para antena GPS


  • Slot de antena GSM


  • gases

    Gases
    SO2, NO2, CO, O3, TVOCS, H2S e NH3

  • data display

    Exibição de dados

  • other

    Outro
    Noise & PM (1, 2.5, 10), Temperature, Humidity and Pressure.

  • weather

    Tempo
    LUX, velocidade do vento, direção do vento, UV e precipitação

Ambient PM

ambient-pm-monitor-pranaair

  • wifi switch

    Interruptor Wi-Fi

  • sim slot

    Slot SIM

  • power supply

    Poder

  • pm inlet

    Entrada PM

Ambiente Lite

ambient-lite-monitor-pranaair

  • Fan

    Fan

  • micro sd card

    Slot para cartão Micro SD

  • rs-485

    Slot RS-485

  • sim slot

    SIM Slot

  • usb power supply

    Fonte de alimentação USB


  • Slot para antena GPS


  • Slot de antena GSM

Ambient Pro


  • gases

    Gases
    SO2, NO2, CO, O3, TVOCS, H2S e NH3

  • data display

    Exibição de dados

  • other

    Outro
    Noise & PM (1, 2.5, 10), Temperature, Humidity and Pressure.

  • weather

    Tempo
    LUX, velocidade do vento, direção do vento, UV e precipitação

Technical Specifications

  • Parâmetros básicos:

  • IQA, PM1, PM2.5, PM10, temperatura e umidade
  • PM básico + estação meteorológica:

  • Parâmetros básicos + LUX, Irradiância Solar, Velocidade do Vento, Direção do Vento, Precipitação, Rajada e Vento. Índice UV
  • Conectividade

  • Wi-Fi ou GSM
  • Peso:

  • 600g (aprox.)
  • Intervalo de dados:

  • 30s a 1 hora
  • Tipo USB:

  • MicroUSB
  • Aplicativo móvel:

  • Aplicativo AQI (disponível para iOS e Android)
  • Dimensões:

  • 16.5 x 5 x 11.5 (cm)
  • Armazenamento:

  • Armazenamento em nuvem AQI
  • Habitação

  • À prova de intempéries
  • Parâmetros:

  • Ambiente PM + CO2, NO2, CO, SO2, O3, NO, TVOC(MOS) and H2S
  • Conectividade

  • Wifi ou GSM(4G) e RS-485 (MODBUS)
  • Peso:

  • 2Kg (aprox.)
  • Bateria:

  • 5000mAh (opcional)
  • Tipo USB:

  • MicroUSB
  • Armazenamento on-line:

  • Armazenamento em nuvem AQI
  • Intervalo de dados:

  • 30 segundos a 1 hora
  • Aplicativo móvel:

  • (disponível para iOS e Android)
  • Dimensões:

  • 20.5 x 14 x 38 (cm)
  • Bateria reserva:

  • 4 horas
  • Habitação

  • À prova de intempéries e compacto
  • Armazenamento off-line:

  • Armazenamento em cartão Micro SD
  • Parâmetros:

  • Ambient Lite + O3, CH4, Ruído, NH3, LUX, Velocidade do Vento, Direção do Vento, Precipitação e Índice UV
  • Conectividade

  • Wifi ou GSM(4G) e RS-485 (MODBUS)
  • Peso:

  • 1.4 kg. (Aprox.)
  • Bateria:

  • Tipo USB:

  • Intervalo de dados:

  • 30 sec to 1 Hour
  • Aplicativo móvel:

  • AQI Mobile App
  • Dimensões:

  • 18 X 38 (cm)
  • Armazenamento:

  • Armazenamento em nuvem AQI
  • Habitação

  • À prova de intempéries
Ambiente PM
  • Parâmetros básicos:

  • IQA, PM1, PM2.5, PM10, temperatura e umidade
  • PM básico + estação meteorológica:

  • Parâmetros básicos + LUX, Irradiância Solar, Velocidade do Vento, Direção do Vento, Precipitação, Rajada e Vento. Índice UV
  • Conectividade

  • Wi-Fi ou GSM
  • Peso:

  • 600g (aprox.)
  • Intervalo de dados:

  • 30s a 1 hora
  • Tipo USB:

  • MicroUSB
  • Aplicativo móvel:

  • Aplicativo AQI (disponível para iOS e Android)
  • Dimensões:

  • 16.5 x 5 x 11.5 (cm)
  • Armazenamento:

  • Armazenamento em nuvem AQI
  • Habitação

  • À prova de intempéries
Ambiente Lite
  • Parâmetros:

  • Ambiente PM + CO2, NO2, CO, SO2, O3, NO, TVOC(MOS) and H2S
  • Conectividade

  • Wifi ou GSM(4G) e RS-485 (MODBUS)
  • Peso:

  • 2Kg (aprox.)
  • Bateria:

  • 5000mAh (opcional)
  • Tipo USB:

  • MicroUSB
  • Armazenamento on-line:

  • Armazenamento em nuvem AQI
  • Intervalo de dados:

  • 30 segundos a 1 hora
  • Aplicativo móvel:

  • (disponível para iOS e Android)
  • Dimensões:

  • 20.5 x 14 x 38 (cm)
  • Bateria reserva:

  • 4 horas
  • Habitação

  • À prova de intempéries e compacto
  • Armazenamento off-line:

  • Armazenamento em cartão Micro SD
Ambiente Pro
  • Parâmetros:

  • Ambient Lite + O3, CH4, Ruído, NH3, LUX, Velocidade do Vento, Direção do Vento, Precipitação e Índice UV
  • Conectividade

  • Wifi ou GSM(4G) e RS-485 (MODBUS)
  • Peso:

  • 1.4 kg. (Aprox.)
  • Bateria:

  • Tipo USB:

  • Intervalo de dados:

  • 30 sec to 1 Hour
  • Aplicativo móvel:

  • AQI Mobile App
  • Dimensões:

  • 18 X 38 (cm)
  • Armazenamento:

  • Armazenamento em nuvem AQI
  • Habitação

  • À prova de intempéries

Modes of Connectivity

arrow line

prana air ambient air quality monitors

Devices

arrow line
  • wifi connectivity
    Wifi
  • gsm sim connectivity
    GSM
  • rs-485 connectivity
    RS 485

Tipos de conectividade

arrow icon

micro sd card data storage

SD Card & Cloud Storage

aqi data dashboard and apps

Web-Dashboard, TV & Mobile

Data Accessibility & Analysis

Explore the most versatile ways of air quality data dashboards in various platforms.

  • aqi data web-dasbhoard
  • AQI Web-Dashboard

    Analyze the real-time and historic data of your ambient monitor data on website.

  • world pollution
  • Analysis: World’s most polluted cities and countries.
  • weather data
  • Weather forecast of your current selected location
  • health recommendation
  • Health advice based on real-time air quality index
  • compare the air quality data
  • Compare different air quality parameters of two or more location

aqi data web-dashboard

  • aqi mobile app
  • AQI Mobile App

    Access your ambient air monitor data on the app.

  • real-time data
  • Real-time air quality API for accurate global data
  • air quality historic data
  • Insightful Air quality monitoring dashboard
  • world air pollution data
  • World air pollution map and weather map
  • compare air quality data
  • Compare different air quality parameters of two or more location

aqi mobile app

  • aqi tv app
  • AQI TV App

    Display your ambient monitor data on big TV screen.

  • compare air quality data
  • Outdoor vs Indoor Air Quality data
  • historic data on tv
  • 24*7 remote access to the monitored data
  • aqi data on tv
  • AQI TV app controlled by AQI mobile app.
  • choose aqi tv app theme
  • Choose from multiple ranges of themes.

aqi tv app

Web-Dashboard
  • aqi data web-dasbhoard
  • AQI Web-Dashboard

    Analyze the real-time and historic data of your ambient monitor data on website.

  • world pollution
  • Analysis: World’s most polluted cities and countries.
  • weather data
  • Weather forecast of your current selected location
  • health recommendation
  • Health advice based on real-time air quality index
  • compare the air quality data
  • Compare different air quality parameters of two or more location

aqi data web-dashboard

Mobile App
  • aqi mobile app
  • AQI Mobile App

    Access your ambient air monitor data on the app.

  • real-time data
  • Real-time air quality API for accurate global data
  • air quality historic data
  • Insightful Air quality monitoring dashboard
  • world air pollution data
  • World air pollution map and weather map
  • compare air quality data
  • Compare different air quality parameters of two or more location

aqi mobile app

TV App
  • aqi tv app
  • AQI TV App

    Display your ambient monitor data on big TV screen.

  • compare air quality data
  • Outdoor vs Indoor Air Quality data
  • historic data on tv
  • 24*7 remote access to the monitored data
  • aqi data on tv
  • AQI TV app controlled by AQI mobile app.
  • choose aqi tv app theme
  • Choose from multiple ranges of themes.

aqi tv app

quote-icon-ambient
Ambient Air Quality Monitoring is one of the primary aspects that govern environmental stability. Air quality is dynamic. Several factors control the air quality of a place. There are numerous natural, industrial, and anthropogenic sources that emit air toxins. Meteorological factors also alter and impact air quality. Outdoor air pollution does not just jeopardize the living. It is also detrimental to the ecology and the atmospheric chemistry of the earth. Thus, outdoor air monitoring is essential.

Ambient Air Quality Monitoring Devices

Outdoor air quality monitoring is an integral part of environmental assessments. Proper air monitoring helps in the formulation of an efficient action plan to mitigate air pollution. Conventionally, the Continuous Ambient Air Quality Management System (CAAQMS) used for ambient air monitoring is a very extensive and expensive set-up. However, not only does our device exemplify efficiency, but it is also compact and cost-efficient.



The primary aspect for determining environmental stability is the Continuous Ambient Air Quality Monitoring System (CAAQMS). There are many factors that control the quality of air and many sources contributing to it such as natural, industrial and anthropogenic. Meteorological factors also alter and impact air quality. Outdoor air pollution does not just jeopardize the living. It is also detrimental to the ecology and the atmospheric chemistry of the earth. Chronic Obstructive Pulmonary Disease (COPD) and asthma are examples of bad air quality for human health. Thus, outdoor air monitoring is essential. Conventionally, the Continuous Ambient Air Quality Management System (CAAQMS) used for ambient air monitoring is a very extensive and expensive set-up as it involves regular filter changes, and importing regulations. Prana Air provides ambient air quality monitors that are easy to use, portable, and highly accurate and cost-effective. The monitors come with detecting sensors for particulate matter, nitrogen dioxide, sulfur dioxide, hydrogen sulfide, carbon monoxide, and ozone based on different sensing techniques.



Using Continuous Ambient Air Quality Management System helps you to assess pollution extent, create awareness among the general public, decisions, and policymaking, and provides you with data for air quality model evaluation and emission control strategies.

Prana Air CAAQMS vs Traditional CAAQMS

Pollutants

Monitor Size

Real-time Data

Portability

Device Cost

Manpower

Accuracy

Technology

Data Accessibility

Prana Air CAAQMS

PM10, PM2.5, SO2. NO2, O3, CO
Compact & lightweight
In less than 30 seconds.
Easy portability
Low cost
Very less manpower
Highly accurate & precise
Sensor based
Available on website, mobile & TV app

Traditional CAAQMS

Technology such as BAM
Huge and bulky
In 20-25 minutes.
Restricted portability
High cost
Intensive Manpower
Highly accurate results
BAM/ Gravimetric etc.
Centralized government websites
  • prana air ambient caaqms monitor
  • Prana Air Ambient Air monitor is CAAQMS (Continuous Ambient Air Quality Monitoring System) installed with sensors to detect the concentration of pollutants like PM10, PM2.5, SO2. NO2, O3, H2S, NH3, CO, etc. Prana Air monitor is smart, economical, easy to use, portable, compact lightweight, and consumes very less time for analysis and has Wi-Fi, GSM, and RS-485 type connectivity. The data is shown on a digital screen and provides 24×7 access to analytic results. The real-time data is given in less than 30 seconds with accuracy and precision.
  • traditional caaqms (Continuous Ambient Air Quality Monitoring System)
  • Traditional CAAQMS (Continuous Ambient Air Quality Monitoring System) is very big in size comparable to a small room. The system has different analyzers for different parameters such as BAM for Particulate Matter, pulsed UV fluorescence for SO2, chemiluminescence for NO2 and NH3, NDIR (Non-Dispersive Infrared Technology) for CO2, and UV photometric/ chemiluminescence for O3 and gives real-time data within 20-25 minutes. The system is bulky & huge and hence its portability is restricted. It requires manpower and high maintenance cost.

Beta Attenuation Mass (BAM) Monitor

Prana Air’s high-end, but low-cost, accurate and reliable air quality monitoring system

Know More

Data Accuracy Graph

In a study comparing the data accuracy of Prana Air’s PM2.5 monitor to a high-end BAM monitor, the results showed that the two monitors were highly correlated.

prana air sensor data accuracy graph

prana air data accuracy comparison

How are Prana Air’s sensors very reliable and accurate?

150+

Constructions
Sites Covered

  • DPCC Logo
  • Acc. to
    DPCC Guidelines

Case Studies

Here are some of the top organizations that have installed our ambient monitors.

Air Quality Sensors

Prana Air’s sensors are the most accurate and reliable sensors on the market, providing real-time monitoring of a wide range of air pollutants.
Know How

Our Clientele

Get in Touch With Us

Please let us know your requirements
so we can get back to you soon.

Contact Info

Looking for Ambient Air Quality Monitors?

  • Phone Number:
    (+91) 73918-73918
  • Email Address:
    [email protected]
  • Office Location:
    706, 7th Floor, Sec 10,
    Rohini, Delhi 85, India

    FAQs About Prana Air’s Ambient Monitors

    CAAQMS is Continuous Ambient Air Quality Monitoring System that monitors outdoor air quality parameters. The parameters are PM10, PM2.5, SO2. NO2, O3, H2S, CO, NH3, etc.

    CAAQMS is necessary as it monitors pollutants using different analyzers based on different working principle. This helps in reducing manual error chances. CAAQMS can generate data with high accuracy in a few minutes and the data is disseminated to general public through its display screen.

    Ambient Air Quality Monitoring System is needed at places where the air is polluted majorly through vehicular and industrial emissions such as at airports, bus stations, railway stations, mining industries, universities, schools etc.

    This monitor is user-friendly, low-cost and gives all the essential necessity to analyse the data, and has the similar accurate data as compared to the highly expensive devices. The comparison chart is shown on the above section of the page.

    Prana Air ambient air quality monitor is applicable only outdoor as the name itself is ambient.

    Prana Air ambient air quality monitoring system has 2 product variants – Ambient Lite and Pro.

    Any user can access the data from the monitor through various ways like WiFi, GSM SIM, RS485 in AQI mobile applications of android & iOS, smart TV & web dashboard.

    Yes, not only mobile applications, but smart TV application is also available.

    We have different data plans in terms of license on the basis of monthly, quarterly, or annually at a fixed cost. In free plan, you can only access the real-time data and all the other features of dashboard will be restricted.

    Yes, we give a 1-year warranty for the ambient air quality monitor only on manufacturing defects.

    Yes, Device Calibration: Usually, the sensors last 3 years without calibration. In case, if you experience a huge drift on the device calculation, the sensor has to be calibrated or changed. In this case, the monitor has to be returned to our premises and the replacement of sensors will be done free of cost if it is under warranty. For out of warranty, the replacement will be done on additional cost.

    You can directly contact our support team.

    Call at 07391873918 or email – [email protected]
